Telaio
29″, super lite AL-6061 tubing, BES III, PowerTube battery
-
Forcella
Suntour XCM34 LO, 120 mm, rebound adjust, 15×110 mm axle
-
Motore
Bosch Performance Line CX, Gen. 4, BES3, 250 W, 36 V, max. 25 km/h
-
Batteria
Bosch PowerTube, 36 V Li Ion, 625 Wh
-
-
Caricatore
Bosch Standard Charger, 4A
-
Deragliatore posteriore
Shimano Deore, RD-M5120, Shadow Plus
-
Leve del cambio
Shimano Deore, SL-M4100, 1×10-speed, rapidfire plus-shifter
-
Guarnitura
FSA CK-320, 34t, 170 mm
-
Movimento Centrale
Bosch, Isis
-
Catena
KMC e10S
-
Cassetta
Shimano Deore, CS-M4100, 11-46t
-
Leve del freno
Shimano BL-M4100, hydraulic disc brake
-
Freni
Shimano BR-MT410, hydraulic disc brake
-
Disco del freno
Front: Shimano SM-RT30, 203 mm
Rear: Shimano SM-RT30, 180 mm -
Manubrio
Syncros Hixon 2.0, mini riserbar, rise: 15 mm, width: 740 mm
-
Attacco manubrio
Satori Viper, 0°
-
Reggisella
Syncros M3.0
-
Sella
Syncros Tofino 2.5
-
Serie sterzo
Acros, A-Headset, semi-integrated, 1.5″, with integrated cable routing, with block lock
-
Mozzo anteriore
Shimano HB-MT400-B, centerlock, disc, 15×110 mm axle
-
Mozzo posteriore
Shimano FH-MT400-B, centerlock, disc, 12×148 mm axle
-
Raggi
stainless, black
-
Cerchio
Cross X18, disc, eyelets, width: 30 mm
-
Gomma anteriore
Schwalbe Nobby Nic Performance, 29×2.60″
Tube: Schwalbe SV19FB Light -
Gomma posteriore
Schwalbe Nobby Nic Performance, 29×2.60″
Tube: Schwalbe SV19FB Light -
PEDALI
MTB alloy
-
Accessori
Kickstand: Syncros
-
Peso in kg (approx.)
26,8
-
Colore
shiny highland grey
-
